CRO Cal-OSHA Compliant Anchors – Specs
Technical Specifications | |
---|---|
Device | Permanent commercial flat/low slope roof anchor for window washing suspension |
Riser Height | 8″/12″/18″/24″/30″/36″ and Custom Heights |
Fall Protection Rating | Fall Arrest and Fall Restraint, 1 person |
Anchor Service Radius | 360-degrees |
Structure Attachment | See Instruction Manual for Minimums |
Fastener Options | See Instruction Manual for Minimums |
Minimum Deformation | 5,000 pounds |
Minimum Tensile | 5,000 pounds |
Ultimate Capacity | 7.500 pounds |
Proof Loading | 2,500 pounds maximum for part numbers with “W” suffix |
4-to-1 Design Load | 1,250 pounds |
Material Domestic | A-36 Steel, 304 Stainless Steel, 316 Stainless Steel |
Material Imported | Q235 Steel |
Finish | ASTM 123 or Hot Dip Galvanized (HDG) |
Temperature Rating | -30 degrees Fahrenheit up to 130 degrees Fahrenheit |
Maximum User Weight | 340 pounds including tools and equipment |
3rd Certification | Dynamark & D.H. Glabe |
OSHA Standard | 1926:502 and 1910.140913) |
ANSI Standard | Z359.1-07 and A10.32-2012 |
CSA Standard | Z259.11-05 for applicable products |
IWCA Standard | 1-14.1 Window Washing |
Cal-OSHA Standard | Title 8, section 3291 Roof Tie Backs where applicable |
